برد کنترلر 1 5 RAMPS - پرینتر سه بعدی

مادربرد پرینتر سه بعدی Motherboard 3D Printer



Product Parameters

Size: 101.5 * 60.5mm
Support motor drivers: support A4988 DRV8825 and other motor drivers(support five motor drivers Simultaneously
Input voltage: 12V
Power: 200W
Patch MOS tube: B55NF06



RAMPS1.5 is optimized and launched based on RAMPS1.4 by Biqu R & D team
They change the original plug-in MOS tube to patch-type MOS tube in order to solve the problem of plug-in MOS tube easy to break, take up a large area, poor heat dissipation , which can improve the stability and aesthetics of the board
The features of multiple extended interface and replaceable parts make RAMPS1.5 become a control board with powerful upgrade capability and scalable modularity
The controller board can be used when the pins on the back of the board are connected to the Arduino Mega and the front is connected to stepper motor drives
